Manufacturer & supplier of G41300 Pipe Flanges and SAE 4130 Pipe flanges in India
The standards vary as ANSI, ASME and other international standards with varying dimensions. The size of the flanges ranges from ½ inches through 60 inches. The Aisi 4130 Material is made up of carbon, manganese, silicon, sulfur, nickel, chromium, molybdenum, phosphorus and 97% iron in the composition. The material also has 560MPa minimum tensile strength and 460MPa minimum yield strength. The Wnr 1.7218 Slip on Flanges are used in precise applications to slip the pipes through the flanges to have precise connections. The slip on flanges are some of the most commonly used flanges in piping applications. There are threaded, screwed and other types of flanges. The Alloy Steel AISI 4130 Threaded Flange can be easily fitted with threaded pipe ends. Usually, the flanges have female threads and are connected with male threaded pipe ends. Sometimes the threaded flanges are also welded for more secure connection. Regal Sales Corporation is a leading manufacturer and supplier of the different types of flanges such as the SAE 4130 blind flanges in this grade of material Please feel free to contact us for more information and pricing of the different types such as the Chromoly 4130 weld neck flanges.
AISI 4130 Flanges
SAE 4130 Flanges
G41300 Pipe Flanges
Table of Content
- What is AISI 4130 Flanges ?
- G41300 Pipe Flanges material standards and grades
- Available types of SAE 4130 Flanges
- Chemical Formula of Chromoly 4130 Flange
- UNS G41300 Flanges Mechanical Strength Table
- Equivalent material grade of AISI 4130 Flanges
- Low alloy steel AISI 4130 Pipe Flanges Weight
- SAE 4130 material Dimensions
G41300 Pipe Flanges belong to the ASTM A182 specification and are used in high pressure high temperature applications such as oil and has, heat exchanger and in power generation units. There are different types but the AISI 4130 blind flanges are special in that they are used to close a pipeline than continuing it. It is useful in test systems and cleaning the pipelines.
| Standards | GOST Flange, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092, BS, BS4504, BS 10, EN-1092, DIN, ANSI, ASME, DIN, MSS S44, ISO70051, ANSI/ASME B16.5, ASME/ANSI B16.5/16.36/16.47A/16.47B, B16.47 Series A & B, B16.48, EN |
|---|---|
| Pressure Rating ANSI | Class 1500, Class 150, Class 900, Class 2500, Class 300, Class 600, |
| Pressure Calculation in DIN | 10Bar, 16Bar, 25Bar, 40Bar, 6Bar, / PN16, PN64, PN40, PN25, PN10, PN6 |
| JIS | 16 K, 20 K, 5K, 10 K, 40 K, 63 K, 30 K, |
| UNI | 10Bar 16Bar 6Bar 25Bar 40Bar |
| EN | 6Bar 25Bar 40Bar 10Bar 16Bar |
| Most common Types | Threaded / Screwed / Forged / Plate |
| Production technique |
|
| Shapes and Types we produce | Large Male-Female (LMF), Ring Type Joint (RTJ), Flat Face (FF), Small Tongue, Small Male-Female (SMF),Raised Face (RF), Large Tongue & Groove, Groove, Lap-Joint Face (LJF) |
| Test | Direct-reading Spectrograph, Magnetic particle detector, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector |
| Equipment | Pushing Machine, Press machine, Bending machine, Sand-blasting machine, electric bevelling machine etc |
ASME SA182 AISI 4130 Forged Flanges
DIN 1.7218 Plate Flanges
Chromoly 4130 High Hub Blind Flanges
AISI 4130 grade Socket Weld Flanges
Alloy Steel AISI 4130 WNRF Flange
SAE 4130 Weldoflange
ASTM A182 UNS G41300 Long Weld Neck Flanges
Aisi 4130 Reducing Flanges
Uns G41300 Slip On Flanges
JIS G4105 Spade Flange
AISI 4130 grade SORF Flange
Chromoly 4130 Spectacle Blind Flanges
DIN 1.7218 Weld Neck Flanges
ASME SA182 AISI 4130 Raised Face Flanges
ASTM A182 UNS G41300 Square Flanges
SAE 4130 Lap Joint Flanges
Aisi 4130 Threaded Flanges
Alloy Steel AISI 4130 Orifice Flanges
JIS G4105 Ring Type Joint Flanges
Uns G41300 Blind Flanges
Provide Minimum Quantity Wnr 1.7218 Ring Type Joint Flanges, Alloy Steel AISI 4130 Loose Flange and UNS G41300 Weld Neck Flanges
| Grade | C | Mn | Si | P | S | Fe | Mo | Ni | Cr |
| AISI 4130 | 0.28-0.33 | 0.40-0.60 | 0.15-0.35 | 0.035 max | 0.025 MAX | 97.3-98.22 | 0.15-0.25 | 0.50 max | 0.80-1.10 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.85 g/cm3 | 1432 ℃ | 560 | 460 | 21.50% |
View Aisi 4130 Equivalent, Weight, temperature rating, Manufacturers of A182 G41300 Forged Flanges, Werkstoff 1.7218 Industrial Flanges in India
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN |
| AISI 4130 | 1.7218 | G41300 | JIS G4105 | BS 970 | 25CrMo4 |
| Standard | Class | Diameter | Bolt Circle Diameter | Number of Bolts | Bolt Size | Diameter of Bolt Hole |
|---|---|---|---|---|---|---|
| AS4087 Flanges | PN14 Flanges | 95 | 67 | 4 | M12 | 14 |
| AS 2129 Flange | Table C Flanges | 95 | 67 | 4 | 13 | 14 |
| Table D Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table E Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table F Flanges | 95 | 67 | 4 | 13 | 14 | |
| Table H Flanges | 114 | 83 | 4 | 16 | 17 | |
| Table J Flanges | 114 | 83 | 4 | 16 | 17 | |
| ANSI B16.5 Flanges | ANSI 150 Flanges | 89 | 60 | 4 | 13 | 16 |
| ANSI 300 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 600 Flanges | 95 | 67 | 4 | 13 | 16 | |
| ANSI 900 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ANSI 1500 Flanges | 121 | 83 | 4 | 19 | 22 | |
| ISO 7005 (DIN) Flange | PN6 Flanges | 80 | 55 | 4 | M10 | 11 |
| PN10 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN16 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN20 Flanges | 90 | 60.5 | 4 | M14 | 16 | |
| PN25 Flanges | 95 | 65 | 4 | M12 | 14 | |
| PN40 Flanges | 95 | 65 | 4 | M12 | 14 |
